Managing Coldwater Fish Populations in a Changing Climate

Overlooking a lake
Figure 1. Voyageurs National Park is a water-based park located in northern Minnesota along the Canadian border of the United States.

Background

Voyageurs National Park (Voyageurs; Figure 1) encompasses part or all of four large lakes and 26 smaller interior lakes, and many of the lakes are home to native coldwater fish including lake trout, lake whitefish, and cisco. Climate scientists predict a 2 - 5 °C (3.6 - 9.0 °F) increase in mean annual temperature by the end of the 21st century for this region, and the surface temperatures of inland lakes in this region are expected to increase by 1 - 7 °C (1.8 - 12.6 °F) during summer. Higher temperatures can affect physiological functions in fish, and as a consequence, coldwater fish populations that are faced with warming conditions may decrease in abundance or fail to persist. Higher temperatures are also expected to be accompanied by lower dissolved oxygen concentrations (oxygen in the water that is available to fish) in most lakes. Therefore, suitable habitat for coldwater fish species is expected to decline. This may lead to the elimination of some populations of these fish, especially along the southern edge of their distribution, an area that includes Voyageurs National Park.



Climate Change and Coldwater Fish Species

Because coldwater fish species require cold water with sufficient levels of dissolved oxygen (DO), they are especially vulnerable to climate change. In summer, their habitat is frequently restricted to the lower portion of the water columns of lakes, where suitably cold water temperatures are maintained through the open water season. However, oxygen concentrations in those areas decline throughout the summer because decomposition of organic materials that settle into those areas consumes oxygen. Water temperatures in the upper layers of the water column become too warm for coldwater fish during the summer, thus limiting coldwater fish to a specific layer of habitat, where both water temperature and oxygen levels allow their survival (Figure 2). In especially warm years, this habitat may disappear altogether, leading to mortality events in the affected populations (Figure 3)1&2.


temperature and oxygen graph of water

Figure 2. Due to temperature and oxygen requirements of coldwater fish, climate change may restrict available habitat. Increased solar radiation will expand the zone of warm surface water, while metabolic processes will eliminate oxygen in a larger portion near the bottom of the water column in a warmer climate, decreasing habitat suitable for coldwater fish (smaller band of suitable habitat after warming shown in bottom panel). Adapted from Ficke et al. 20071.


Dead cisco fish
Figure 3. Dead cisco from a summer mortality event in Lake Andrusia, Minnesota in 2006.

Photo Credit: Peter Jacobson, Minnesota Department of Natural Resources


View of lake with tree line and rocky shore.
Figure 4. Little Trout Lake. The National Park Service is currently monitoring coldwater fish habitat in Little Trout and Mukooda lakes to assess whether this habitat is contracting.

Photo Credit: Geoffrey Smith

Outlook

Studies predict the degradation of coldwater fish habitat due to warmer water temperatures in the upper water column and less oxygen in the deeper water (Figure 4). As a result, it is expected that coldwater fish will be eliminated in many regional lakes but will persist in some lakes that are deep enough to maintain cold, well-oxygenated water—including some lakes along the northern edge of the contiguous United States (e. g. Voyageurs National Park).

The dispersal of other fish species in response to a warming climate may also have significant impacts on coldwater fish. As lakes become warmer over the next century, conditions will become favorable to species like smallmouth bass.Smallmouth bass are ferocious predators and can greatly reduce populations of many important prey species available to lake trout. Lake trout must then shift their diet to less energetically efficient prey items, which can negatively impact their growth, reproduction, and survival rates.

Coldwater fish species are especially vulnerable in lakes receiving excess nutrients. Temperature increases can enhance the productivity of lakes by increasing nutrient cycling rates, exacerbating the problem of excess nutrients. Increasing temperatures would likely be accompanied by increases in lake productivity, which would further reduce oxygen levels in lakes by increasing the amount of decomposing organic material in lakes.


Overlooking Rainy Lake
Figure 5. Rainy Lake, the largest lake of the Rainy Lake—Namakan Reservoir system.

Management Implications

  • Refuge lakes have been identified in Minnesota for cisco, a coldwater fish species, and some of these lakes are within Voyageurs National Park3. The refuge lakes are deep, have generally good water quality, and maintain adequate oxygen conditions even in warm summers. Research shows that cisco are likely to persist in these lakes in a warmer climate. Coldwater fish are currently present in Rainy (Figure 5), Kabetogama, Namakan, Sand Point, Cruiser, Little Trout, Mukooda, Locator, and War Club lakes within Voyageurs National Park.
  • Monitoring and managing nutrient inputs is important for protecting coldwater fish habitat in Voyageurs National Park lakes.This will help ensure that sufficient levels of DO will persist in the water column.
  • Recent surveys in Little Trout and Mukooda lakes suggest that the resident lake trout populations have declined; lake trout harvest has been suspended in these two lakes to allow the populations to recover. Preliminary lake temperature and stratification studies revealed that factors other than temperature and DO may be contributing to the observed declines.
  • Voyageurs National Park has taken measures to prevent the spread of exotic species by setting regulations and Best Management Practices (BMPs). If the impact of exotic species can be minimized, it will limit one stress impacting coldwater fish in these lakes.




References

1Ficke, A.D., Myrick, C.A., and Hansen, L.J. 2007. Potential impacts of global climate change on freshwater fisheries. Reviews in Fish Biology and Fisheries.17:581–613.

2 National Fish, Wildlife and Plants Climate Adaptation Partnership. 2012. National Fish, Wildlife and Plants Climate Adaptation Strategy. Association of Fish and Wildlife

Agencies, Council on Environmental Quality, Great Lakes Indian Fish and Wildlife Commission, National Oceanic and Atmospheric Administration, and U.S. Fish and Wildlife

Service. Washington, DC.

3 Jiang, L., Fang, X., Stefan, H.G., Jacobson, P.C., and Pereira, D.L.2012.Oxythermal habitat parameters and identifying cisco refuge lakes in Minnesota under future climate scenarios using variable benchmark periods. Ecological Modelling.232: 14-27.
