Flubber Glacier Model

NPS photo

Objective: Determine how different conditions affect the flow of ice (flubber)



NPS photo

Materials:

• ruler/measuring tape
• stopwatch
• PVC pipe (~1m, cut lengthwise)
• markers
• Flubber
  • warm water
  • white glue (Elmer's)
  • Borax
  • food coloring (optional)



NPS photo

Make the Flubber

1. In one container, combine the following:

• 3/4 C. warm water
• 1 C. white (Elmer's) glue
• food coloring

2. In another container, combine the following:

• 2 tsp Borax
• 1/2 C. warm water

3. Combine the two mixtures and work through the hands until it achieves a consistent texture
4. Repeat so that you have three (3) batches of Flubber, each a different color

• put one in the refrigerator
• put one in a container floating in hot water
• leave one at room temperature conditions



NPS photo

Experiment!

1. Set up two "tracks" of PVC pipe at the same angle
2. Run the experiment twice, comparing the hot and cold Flubber to the room temperature Flubber
3. Hold both Flubbers at the same position at the top of the track
4. Release the Flubber! and start the stopwatch
5. Every thirty seconds, use the measuring tape to record how far the Flubbers have flowed



Use a marker to draw parallel lines on the flubber and watch how they distort as it flows.

NPS photo

For variations on the experiment, you can try changing the angle of the PVC pipe to make it steeper or shallower. You can also put sandpaper or cooking oil on the "valley" to increase or decrease friction.

Which flubber flowed faster: hot, cold, or room temperature?

Why do you think that is?

How do you think using sandpaper or oil would change the way the flubber flowed?
