The following images show off some geologic terms you might encounter along the trail. For a more comprehensive list, check out the glossary from the Ice Age Floods Institute.


Basalt
Basalt
A dark igneous volcanic rock composed of primarily two minerals: plagioclase and pyroxene. Over a period of 11 million years (17 to 6 million years B.P.) hundreds of flows of Columbia River basalt were extruded from long, linear vents in southeastern Washington, northeastern Oregon and west-central Idaho and traveled for hundreds of miles before cooling and solidifying to form the Columbia Plateau.

NPS Photo


Steptoe Butte
Butte
A conspicuous, isolated, generally flat-topped hill with relatively steep side slopes, often capped by a more resistant layer of rock and bordered by talus. Often represents an erosional remnant, smaller in extent than that of a mesa, carved from flat-lying rocks.

NPS Photo


Channeled Scablands
Channeled Scabland
An eroded, interconnected network of streamlined loess islands, flood channels, coulees, cataracts, and plunge pools scoured into basalt by cataclysmic floods in eastern Washington State. These features are unique to this region of the Earth, however they are similar to channel networks observed on Mars.

NPS Photo


Coulee
coulee
A long, dry, steep-walled, trench-like gorge or valley representing an abandoned river channel. In south central Washington, the term coulee is mostly used for an abandoned ice-age flood channel.

NPS Photo


Erratic
Erratic
A rock fragment carried by floating ice, deposited at some distance from the outcrop from which it was derived and generally composed of a different type of rock than the local bedrock.

IAFI Photo


Giant Current Ripples
Giant current ripples (GCRs)
Extremely large waveforms created by the transport and deposition of coarse-grained* flood material during Ice Age floods. They develop at right angles to the direction of flow, much the same as the smaller ripples we see along modern beaches and river bottoms. GCR's, composed of coarse-grained sand and gravel, have wavelengths of 100-400 ft and amplitudes of 3-25 ft (Baker 1978). The dimensions of the ripples give scientists a method for estimating the depth and spe

NPS Photo


Hanging Valleys
Hanging valley
A tributary valley whose floor is notably higher than the valley it joins. Characteristic of flood coulees, where flat valley floors suddenly drop off abruptly at one or both ends where they join adjacent coulees.

NPS Photo


Talus
Talus
Broken rock accumulated at the base or against the lower part of a steep slope or cliff.

NPS Photo


Wallula Gap
Wallula Gap
The narrow constriction, only a few miles wide, through which all floodwaters from glacial Lake Missoula passed on their way to the Pacific Ocean. During the largest floods, the water within Wallula Gap was over 1,200 ft deep.

NPS Photo
