Taft House Elevator Specifications

Select a quicklink below to go directly to that certain specification or scroll down to view all specs for the Taft House Elevator.

• General Specs
• Cab Specs
• Hoistway Specs
• Hall Fixtures
• Car Fixtures
• Additional Features

---



General

Model	Winding Drum
Manufacturer	Inclinator
Capacity	1000 lbs.
Speed	40 FPM
Travel	22 ft. 9 in.
Stops	3
Door Type	Not Available (N/A)
Power Supply	220 V, single phase, 30 amp
HP	2
Controller	Microprocessor (NP)
Emergency Power	Battery Lowering
Drive Type	Double Winding Drum
Machine Room Location	Behind rail/adjacent

Top of Page

---



Cab

Cab Type	200 Series (standard)
Panel Type	Hardwood Veneer
Panel Finish	Not available (N/A)
Cab Gate	Accordian
Cab Gate Finish	N/A
Ceiling	N/A
Ceiling Finish	N/A
Lighting	2 LED lights
Cab Sill	Aluminum
Handrail Type	Matching Wood (standard)
Handrail Finish	N/A
Handrail Location	Car Operating Station Wall
Protective Pads	N/A
Cab Floor	N/A

Top of Page

---



Hoistway

Door Opening Size (WxH)	36 in. x 84 in.
Cab Size (WxD)	36 in. x 48 in.
Hoistway (WxD)	45 in. x 52 in.
Pit Depth	12 in.
Overhead	8 ft. 0 in.

Top of Page

---



Hall Fixtures

Type	Flush or Raised Mount
Finish	N/A
Fixtures	Hall Stations

Top of Page

---



Car Fixtures

Type	Flush or Raised Mount
Finish	N/A
Fixtures Included	Car Operating Panel

Top of Page

---



Additional Features:

• Automatic light shutdown
• Emergency Light
• Flush mount ADA phone
• Door edge that will stop car operation if an object is beyond gate
• Non-proprietary controller
• Audible alarm bell in case of entrapment
• Car top switch
• Pit switch
• Limit switch
• Locked control box
• Emergency stop button
• Programmable homing device
